NZXT H630 Overview
For a full video overview of the case be sure to check out the video below.
The H630 comes in two different colors, which are black and white. As you can see from the photos below we received the black version. While the photos may not show it the black color on the H630 is more of a matte black, which actually works really well here. Like most silent cases the H630 has a very sleek and sophisticated look.
One thing that really gives it the sophisticated look is the separation of the top and front panels. This simple design, which goes away from the norm really gives this case some character. Right at the top of the case you have a larger power power button and a smaller reset button.
The front of the case has an extremely clean look to it. There are only two 5.25-inch drive bays. Many people would say that is not a lot for a full tower case, but who really needs 4 optical drives? It looks like there would be no room for an intake fan, but there is a 200 mm fan behind the front bezel. There are air vents on each side of the case that will get air into your system. On the right side of the case are all of your connections and buttons which include a light on / off button, HD audio connections, 2 USB 3.0 ports, 2 USB 2.0 ports and a card reader. Since NZXT has decided to put all of these connections on the side of the case it preserves the sleek look of the case.
You will find the same air vents that are on the front of the case on the top left of the case. This is in case you want to install fans up top. You can remove the top of the case pretty easily to reveal room for 2x 200mm fans, 2x 140mm fans or 3x 120mm fans. The top of the case also has sound dampening material install on it.
Both side panels of the H630 are completely plain, which is expected as this is a silent case.
Looking at the back of the case we can see the air vents at the top if you have top fans installed. There is a 140 mm rear fan included and like most other NZXT cases it can be easily adjusted to line up with your CPU. Below that there are 9 expansion slots and your power supply will be positioned on the bottom of the case. There is a pull out fan filter on the bottom of the case. Of course your have thumbscrews on each side of the case. One of my favorite features of many NZXT cases is the small LED that will light up the back of the case so it is easer to connect your cables.
On the bottom of the case are 4 large feet and we can also see a large fan filter that you can take out from the front of the case.
