Case Mod Friday: Chessboard

Project Name: Chessboard

Case Mod Friday: Chessboard

About this mod / project:
Dual loop with redundant d5 pumps. One loop for the GPU + Aquaero 5 lt waterblock and another loop for the ram + CPU block. GPU loop – It is a reverse case so the white rads (XSPC 480 and 240) will handle the two titan blocks. This loop is with fittings in white and dark grey liquid. CPU loop – The single 560 mm HWlabs rad on the bottom compartment will handle this loop. The rad, fittings and reservoir are black with white liquid (either Aurora 2 or Pastel).

Photos:

fea98b81_DSCN4965_b f72874d7_DSCN4987 f72874d7_DSCN4987 f831e98f_DSCN4990 e9fa5f14_DSCN4981 e8a5c6bc_DSCN5014 e1e14b6c_DSCN5016_b cd1937f1_DSCN4963_b cadc7234_DSCN4989_b b099da51_DSCN4988_b ad5fc884_DSCN4984 aacdd2db_DSCN5015_b aa5e04d6_DSCN4964_b 434183d7_DSCN5012 05030e5e_DSCN4982 4451e6df_DSCN4991_b 4451e6df_DSCN4991_b (1) 801f14f5_DSCN5013_c 369b154c_DSCN4985 346cf9fd_DSCN4959 66cf9f62_DSCN4983 6ad94a89_DSCN4986 2aaa90e6_DSCN4958

Case and accessories
▪ CaseLabs Magnum SMA8 reverse White with flex bay Black
▪ CaseLabs 120.2 Flex-Bay Rad Mount
▪ CaseLabs 120.1 Flex-Bay Fan Mount
▪ XXL Clear windows
▪ Case Caster
▪ PSU mount
▪ CaseLabs 140.4 Rad Side Mount

Components
▪ Asus x99 Deluxe Motherboard
▪ Intel i7 5960x CPU
▪ Gskill 64GB DDR4-2400 RAM (F4-2400c15q-32gnt)
▪ Corsair ax 1200i PSU
▪ EVGA Titan (x2)
▪ Samsung Evo 1 Tb (2x)
▪ Seagate 3 TB 7200 rpm
▪ Samsumg M2 SAMSUNG XP941 512 Gb

Cooling
▪ Phanteks PH-F120S White frame and black blades (x10)
▪ Bitfenix Spectre Pro BFF-LPRO-12025R-RP 140mm White (4x)
▪ Schyte ultra slim 120 mm fan (x4)
▪ XSPC rx v3 480 mm Radiator
▪ XSPC rx v3 240 mm Radiator
▪ Hardware Labs Black Ice SR1 560 mm Radiator
▪ D5 Aquacomputer USB Pump (4x)
▪ EK-D5 X-TOP CSQ – WHITE Acetal
▪ EK-D5 X-TOP CSQ – BLACK Acetal
▪ EK-Multioption X3 250 with white acetal ends
▪ EK-Multioption X3 250 with black acetal ends
▪ EK-UNI Holder D5 (2x)
▪ Shoggy Sandwich
▪ Bitspower enhanced White Crystal Links with a lots of extenders, adapters and 90 degrees
▪ Bitspower enhanced Black Crystal Links with a lots of extenders, adapters and 90 degrees
▪ EK-HD Tube 10/12mm 500mm – 2 pack (10x)
▪ EK Supremacy CPU Waterblock – Clear
▪ EK-RAM Dominator Waterblock – Clear Copper
▪ EK Titan block short clear/nickel (2x)
▪ Ek BLACK backplate (x2)
▪ Mayhem Aurora Green (2x)
▪ Mayhem Red dye
▪ Mayhem Pastel White (x2)
▪ Aquacomputer Aquaero 6 XT USB Fan-Controller
▪ Aquacomputer Black Faceplate for Aquaero
▪ Aquacomputer 5 LT with water block
▪ Aquacomputer Flow sensor mps flow 400, G1/4 (2x)

Sleeving, Cable and lightning
▪ Fan extensions from lamptron controller and led light stripes (white high density) brought locally +solder
▪ Corsair White PSU cables

Mods
▪ Painting ram (White)
▪ Painting radiator (White)
▪ Some holes and pass through in the Caselabs SMA8. Had to cut the bitspower Pass-Through Fitting / Fillport to custom length

Build Log: Overclock.net

Builder: Gabrielzm
