AMD Radeon HD 8970 Pictured!

An alleged photo along with specifications of AMD’s upcoming flagship Radeon HD 8970 graphics card has been leaked by 4Chan of all places. Because of that I would take this report with a grain of salt, but many rumors suggest that AMD’s 8000 series could debut at E3 2013 this week, so who knows this may actually be a real photo of the card.

AMD Radeon HD 8970

Not only was the photo above leaked, but also the specifications of the card. According to them the GPU will be powered by the 28nm Curacao XT core which features 2304 stream processors, 48 raster operators, and 3GB of GDDR5 memory running along a 384-bit wide interface. The core will operate at 1000 MHz or 1 GHz clock speed and the memory will be running at 6500 MHz or 6.5 GHz effective frequency. The TDP is also said to be 250W. The rumored price of the card is said to be $550, which would put it $100 under NVIDIA’s flagship GeForce GTX 780.

The photo shows a cooler design that is much like the one we saw on AMD’s Radeon HD 7990, except that it only has two fans. The fans and side patterns are actually the same. Also on the card we see two CrossFireX connectors and power to the card is by an 8 + 6pin PCI Express power connector.

Here is a graph comparing the Radeon HD 8970 to the Radeon HD 7970.

ThinkComputers.org

AMD Radeon HD 8970

AMD Radeon HD 7970

Die / Core

28nm Curacao XT

28nm Tahiti XT

Stream Processors

2304

2048

Raster Operators

48

32

TMUs

144

128

Memory

3 GB GDDR5

3GB GDDR5

Memory Bus

384-bit

384-bit

Price at Launch

$549

$549

If these cards do make an appearance at E3 we will definitely let you know!

Source: WCCFTech | News Archive
